DT-623 Electronic Thermometer with Flexible Tip

• presence of symptoms of elevated body temperature (e.g., fever, pyrexia);
• need for monitoring body temperature;
• measurement of body temperature.

USAGE OF THE DEVICE FOR MEASUREMENT

1. Press the On/Off button.
2. A sound signal will be heard, and a set of symbols confirming the device's functionality (automatic test) will appear on the display. After this, the result of the last measurement will be displayed for 1 second. Then, the symbols 37 °C will appear on the display.
3. Next, the symbol "Lo" and a flashing °C symbol will appear - the thermometer is ready for use.

METHODS OF MEASURING TEMPERATURE

Oral measurement (measurement time ~1 minute). Place the thermometer tip to the side under the tongue. To obtain an accurate result, keep your mouth closed throughout the measurement procedure.

Axillary measurement (measurement time ~1 minute). Position the thermometer in the center of the armpit (see illustration). For an accurate result, the thermometer must fit as closely as possible to the skin of the armpit. Press your arm against your body and hold it in this position until the measurement is complete.

Rectal measurement (measurement time ~1 minute). Rectal measurement is performed only when prescribed by a doctor or when it is not possible to conduct other methods.

STORAGE AND CARE OF THE MEDICAL DEVICE
• The device casing is not moisture-resistant. Avoid moisture exposure to the thermometer.
• After each use, clean the device as specified in the section "Methods and Means of Disinfection and Pre-Sterilization Cleaning." Always use the device with a clean sensor tip. Contamination of the sensor tip may lead to inaccurate readings.
• Store the thermometer in its case, avoiding direct sunlight, high temperatures and humidity, exposure to liquids, dust, fire, vibrations, and impacts.
• Keep the thermometer away from devices with strong electromagnetic fields (television, radio receiver, microwave oven, mobile phone). Proximity to such devices may affect the accuracy of readings.

Methods and Means of Disinfection and Pre-Sterilization Cleaning
After each use, wipe the thermometer casing with a cloth dampened with a weak soap and water solution. If the thermometer is contaminated, wipe it with a dry soft cloth or a cloth dampened with a weak soap and water solution. Do not use solvents, gasoline, or abrasive cleaning agents.
Sterilization of the medical device is not provided.

Incorrect placement of the thermometer in children due to fecal matter may lead to rectal perforation.

Electronic Thermometer. Model DT-623

The DT-623 electronic thermometer is designed for measuring human body temperature in three ways: orally, axillary (in the armpit), or rectally. The principle of operation of the thermometer is based on measuring the change in resistance due to the heating/cooling of the sensitive element of the sensor; the measurements are processed by an integrated circuit and displayed on an LCD screen. This allows the user to easily read the results. The thermometer should be used in accordance with the rules and precautions specified in the documentation, does not require a specially equipped room for use, nor does it require training or experience from the user, and can be used both at home and in medical facilities.

Function Description:
Last measurement memory - allows viewing the result of the previous measurement upon turning on
Sensor water resistance - allows immersing the thermometer in liquid up to the screen and measuring the temperature of baby food or bath water.
Sound signal - informs about the turning on/off of the thermometer, as well as the completion of the measurement process.
Ability to replace power elements.

• Average measurement time - 60 seconds*
• Mercury-free
• Sound signal
• Last measurement memory
• Accuracy ± 0.1 °C
• Up to 1,000 measurements from one new LR41 power element
• Sensor water resistance
• Flexible tip
• Large display
• Comes with a storage case
• Warranty - 1 year

• Body temperature measurement time is individual for each person and depends on the thermal conductivity of the skin.

Patient Population: Adults and children. Temperature measurement in children should only be performed under adult supervision.

Metrological and Technical Specifications

Measurement Range: From 32.0°C to 43.0°C
Permissible absolute error ±0.1°C
Dimensions, mm, no more than (Length, Width, Thickness): 140x40x20

DT-623 Electronic Thermometer with Flexible Tip - for measuring human body temperature in three ways: orally, in the axilla (axillary), or rectally. Last measurement memory - allows viewing the result of the previous measurement upon activation.

Moisture protection of the sensor - allows the thermometer to be immersed in liquid up to the screen and measure the temperature of baby food or bath water.

Sound signal - informs about the activation/deactivation of the thermometer, as well as the completion of the measurement process.

Ability to replace power elements. Comes with a storage case. Accuracy ± 0.1 °C.

Average measurement time - 60 seconds*
* The time for measuring body temperature is individual for each person and depends on the thermal conductivity of the skin. The thermometer is electronic, mercury-free; with a flexible, non-injurious tip.

Temperature measurement in children should only be performed under adult supervision.
